ODM Type 2 Electric Car Charger Portable EV Home Charger Ground Protection

Name: ODM Type 2 Electric Car Charger Portable EV Home Charger Ground Protection
Brand: HONGJU
Price: 1 USD

Quality ODM Type 2 Electric Car Charger Portable EV Home Charger Ground Protection for sale

Brand Name : HONGJU

Model Number : HJ-EV-PE-02

Certification : ETL,TUV,CCC,ROHS,REACH

Place of Origin : CHINA

MOQ : 200

Price : To be negotiated

Payment Terms : T/T

Supply Ability : 100000PCS Per Month

Delivery Time : 30-40 days

Packaging Details : Each in PE bag, then in Pizza box, then 5 Pizza boxes into 1 master carton Deluxe pack: each in Oxford cloth with zipper & handle, easy for end users to keep

Protection rank : IP55 Cable; IP65 ICCB

Charging cable : 3x2.5mm²+2x0.5mm²

Input power : AC220-250V

Durability : High

Portability : Compact and Lightweight

Power Source : Electricity

Contact Now

Ground Protection ODM Electric Car EV Charger Type 2 Home EV Charging Over Current Protection

Certificates & QC	CE(ICR lab), UKCA, RoHS,TUV mark, ISO
Protection rank	IP54
Cable	IP67 ICCB
LCD display	0.96’’ black and white screen
LED indicator	yellow / red / green
RCD	30m A AC
Input power	250V max
Charging cable	4.5M Type 2 (TPU Jacket)
ICCB size	L243xW90xH53 (mm)
Start mode	plug & play
Operating temperature	-35℃ to 50℃
Warranty	2 years (both cable and ICCB)
lead time	30-35 days after deposit payment
Q'ty basis	based on 500pcs+ each, if lower than 500pcs, price with $2/PCS up, MOQ 100pcs each type
Payment Terms	T/T(30% advanced payment ,the rest 70% balance should be paid before shippment)
Electrical Protection	Over current protection, Residual current protection, Ground protection, Surge protection Over/Under voltage protection, Over/Under frequency protection, Over temp protection
Materials Applied	Shell: black by thermoplastic PC940. Anti-corrosion and abrasion protection. Cable: 4.5M in black with TPU jacket. With CE issued by TUV and TUV mark.
Customizing Logo	Logo put on shell by laser on ICCB box or cable head; on Oxford cloth bag by printing
Package	Each in handover bag, then in Pizza box, then 5 Pizza boxes into 1 master carton Handover bag: Oxford cloth with zipper & handle, easy for end users to keep (extra cost)
Features	Product conforms to Low Voltage Directive 2014/35/EU, IEC61851-1:2019 IP67, Weather proof; Leakage current protection; Impact resistance Charging status and working error simply displayed by LED indicators and LCD screen Optional function of current choice button to switch current from 8A-32A

Electrical Protection

Over current protection, Residual current protection, Ground protection, Surge protection

Over/Under voltage protection, Over/Under frequency protection, Over temp protection

ODM Type 2 Electric Car Charger Portable EV Home Charger Ground Protection

How to make Order

Please send us an email to specify the item, quantity, color or other specification to place an order.

1. Contact us via website. e-mail. whatsapp etc contacting tools, confirm the model & quantity you want to order with us.

2. Contract will be sent to you.
3. You check the contract and make payment.
4. Package will be delivered to you once we receive the payment.

FAQ

1. What's the rated of EV Charging Cable you have?

Single phase16A / Single phase 32A / Three phase 16A / Three phase 32A

2. Can I print my own logo?

Yes MOQ 100pcs. There is no extra fee.

3. Can I customzie different color for the connector or cable?

Yes of course. MOQ 500pcs.

4. How is the warranty?

Same Q'ty good cables compensation against same Q'ty bad ones

5. How long is the lead time?

For sample order, we can ship in 2 to 5 days. For mass order, around 15 to 30 days.

6.Can I visit your company before placing the Order.

Yes. You can visit any time.
